产品展示

GFCK/25给袋式重袋包装机组

  • 推荐关键词搜索:包装机|给袋式包装机|颗粒给袋包装机|

    产品简介:

        该机组主要是完成将散装物料装入编织袋、缝包输出的全自动包装过程,该机组包括编织袋全自动包装机、全自动缝包机、产品输送机。

        编织袋全自动包装机可实现自动上袋、开袋、计数、填充、移动输出、导入全自动缝包机自动实现缝包。实现包装过程无人化。

        该机组采用触摸屏控制,人机关系更加良好,操作、规格切换、维修十分方便,安全可靠。

    技术参数:

    1. 小袋产品:固体、颗粒或液体

    2. 大袋包装机产能≦55pls/min

    3. 四边封包装机抽真空产能≦15plc/min

    4. 气压:≥5Kg/cm2

    5. 功率:根据配置

    VFS5000F4 BAG IN BAG PACKING LINE

    Advantages:

        This unit is used for packing granular grain powder into the woven bag, bag sewing and output, this unit consists of fully automatic packaging machine, fully automatic sewing machine and product conveyor.

        Automatic packaging machine for woven bags can realize automatic bag feeding, bag opening, counting, filling, shifting and output, guiding into automatic sewing machine to realize automatic bag sewing. Realize unmanned packaging process.

        This unit adopts touch screen control, and features better man-machine relation, convenient operation, size change and repair as well as safety and reliability.

    Technical parameters:

    1. Scope of product applicable for packaging of this unit: 5kg~25kg;

    2. Packaging material: hard plastic woven bag, whose size varies with product;

    3. Range of sizes of woven bag: (500~650)*(300~400)*(120~200)

    4. Packaging rate: 2~12 bags/min;

    5. Compressed air: 0.6~0.8MPa, air volume 0.3m3/min;

    6. Power supply: 2.5kW 380V±10% 50Hz.
