CJD50K-WL25K型螺旋称量机组
---适用于,水泥,建材等粉状物料的计量充填

  • 推荐关键词搜索:包装机|建材包装机|粉体计量机|面粉计量机水泥计量机

        该机用荷重传感器称量,采用卧式双螺旋喂料,此方法有效地解决了粉状物料的反扑问题。同时又克服了立式螺旋计量精度不高的问题,适宜于粉状物料的计量充填。该机配有气动夹袋装置,只须人工送袋,操作方便。

    技术参数:

    计量范围:5~25 kg

    计量速度:3~6 次/分

    称量精度:±0.2%~0.5%

    机重:1000 kg

    电源:380 V±10% 50 Hz 5 kW

    CJD50K-WL25K AUTO WEIGHING MACHINE
    ----Suitable flour, condiment, concrete

    This machine adopts loadcell for weighing and horizontal double-auger for feeding. This method effectively solves the problem of kickup of powdery material. Meanwhile it overcomes the problem of low metering accuracy of vertical auger. Therefore, this machine is suitable for metering and filling of powdery products such as flour and flavoring materials. This machine is equipped with pneumatic bag-clamping device, and only needs manual bag feed, so its operation is convenient.

    Features:

    Metering capacity:5~25 kg, max. 50kg

    Metering speed:3~6 times/min

    Weighing accuracy:±0.2%~0.5%

    Machine weight:1000 kg

    Power source:380 V±10% 50 Hz 5 kW
