LB450/2 AUTOMATIC BAGS ARRANGE INCASE MACHINE
The product packaged by the automatic packaging machine passes through conveying line, undergoes unscrambling and arrangement, steering and sequencing, speedup and buffer, loading into paper carton automatically and sequentially at a certain quantity, then undergoes arrangement by the flattening press, finally the paper carton is sealed as required through the fully automatic box sealing mechanism, strapped by the baling machine and finally the paper cartons are output by the logistics line.
Process flow: automatic packaging → weight check or metal detector → collection and shaping line → automatic box opening machine → automatic boxing machine → vibratory flattening → fully automatic box sealing machine → automatic baling machine → working storage section
1. Production capacity of small bags: 120~150pcs/min
2. Weight of small bag: ≥50g
3. The power for boxing and unscrambling adopts Matsushita servo motor
4. The pneumatic components adopt quality products such as SMC, Festo etc.
5. Electrically distributed control, and touch screen display operations
6. Operating air pressure: ≥5kgf/cm2
7. Power of equipment: ≥5 kW (according to setup)
